A first Workshop on one sample invention, a solar float that keeps a rainwater tank fresh. Six pieces, in the order they are made. On a paid plan this is day one: your packet builds as you grow.
Step 1 of 5 · Invention write-up
Solar Circulating Aerator Float
Built from the inventor’s notes and a short conversation.
Abstract
A buoyant unit floats on stored rainwater. A palm-size photovoltaic panel on top powers a low-draw pump and an air stone that circulate and oxygenate the water during daylight. Because the same sunlight that would drive algal growth instead powers the circulation, the water stays moving and oxygen-rich, which suppresses algae without mains power, wiring or chemicals. The unit sits on the surface and needs no change to the tank.
Problem / Unmet Need
- Rainwater held in static storage tanks is exposed to sunlight and sits undisturbed, so it grows algae and goes stagnant, wasting a captured resource.
- Covers and chemical treatments add cost and handling; mains-powered circulation is impractical where rainwater is stored.
- Households and smallholders who harvest rainwater have no low-cost, self-contained way to keep it fresh.
Proposed Solution
A float carries a small photovoltaic panel that drives a low-draw pump and an air stone. During daylight the pump moves the stored volume and the air stone raises dissolved oxygen. Circulation is strongest in the bright, warm hours when algae grow fastest, with no timer or sensor, because the panel and the algae answer to the same sun.
Key Features
- Self-powered: a palm-size photovoltaic panel runs the whole unit, with no wiring or grid connection
- Self-contained float: sits on the surface and needs no change to the tank
- Low-draw DC pump that circulates the stored water
- Air stone diffuser that raises dissolved oxygen alongside the circulation
- Daylight-matched operation: strongest when algae grow fastest, with no timer or sensor
- Built from low-cost, off-the-shelf parts
Who Benefits
- Households that store rainwater for the garden or the home
- Smallholders and community gardens that irrigate from tanks
- Off-grid and low-resource settings where mains power is not at the tank
Assumptions & Unknowns
- The pump and panel sizing that keeps a given tank clear has not yet been confirmed on the inventor's own tank.
- Performance through cloudy spells, when the panel gives less, is not yet characterized.
- Long-term durability of the float, panel and pump under sun and water is not yet tested.
Initial Risks & Mitigations
- Sizing: the pump and panel may be under-sized for a large or heavily sunlit tank. Confirm with a before-and-after clarity check on the target tank.
- Cloudy days: circulation drops when the sun does. A small battery could carry gentle circulation through short cloudy spells.
- Durability: continuous sun and water exposure wear the panel and pump. Use an ultraviolet-stabilized float and a sealed pump that can be swapped.
- Fouling: debris can reach the pump. A removable screen at the intake, cleaned now and then, is the first thing to try.
Billie
Here is your write-up: the problem, how your float solves it, what makes it work, and what could go wrong. Every step after this builds on it.
